Location:Chinese Academy of Sciences > Products  > Carbon Nanotubes MWCNTs
Outer Diameter:4-8nm, 98%(click)Outer Diameter:5-15nm, 98%(click)Outer Diameter:5-15nm, 99%(click)Outer Diameter:8-15nm, 95%(click)Outer Diameter:10-20nm, 90%(click)Outer Diameter:10-20nm, 98%(click)Outer Diameter:20-30nm, 98%(click)Outer Diameter:30-50nm, 98%(click)Outer Diameter:30-80nm, 98%(click)
 Purified Multi-walled carbon nanotubes (TNM0):

Product Code : TNM0, TNMH0, TNMC0
Technical Data (pdf)

TNM0 (Download)
TNMH0 (Download)
TNMC0 (Download)




Product Description:

Property Unit MWCNTs Method of Measurement
TNM0 TNMH0 TNMC0
OD nm 4-8 4-8 4-8 HRTEM,Raman
Purity wt% >98 >98 >98 TGA & TEM
Length microns 10-20 10-20 10-20 TEM
SSA m2/g 350-550 350-550   350-550 BET
ASH wt% <2 <2 <2 TGA
Ig/Id -- -- -- -- Raman
Oxygen Content wt%    5.75   XPS & Titration
Oxygen Content wt%     6.60  XPS & Titration
OD=Outer Diameter           ID=Inner Diameter            SSA=Specific Surface Area
