Product Code : TNWGO，TNWGO-3，TNWGO-10，TNWGO-50
| Technical Data of TNWGO (pdf) (Download) | Technical Data of TNWGO-3 (pdf) (Download) | Technical Data of TNWGO-10 (pdf) (Download) | Technical Data of TNWGO-50 (pdf) (Download) |
Product Description:
| Property | Unit | Graphene Oxide Dispersion（TNGO） | Method of Measurement | ||||||
| TNWGO | TNWGO-3 | TNWGO-10 | TNWGO-50 | ||||||
| Layers | layer | <3 | 1-2 | 1-2 | 1-2 | ||||
| Purity | wt% | >99 | >98 | >98 | >98 | ||||
| Diameter | microns | 0.5-3 | 1-5 | 8-15 | >50 | ||||
| Thickness | nm | 0.55-1.2 | - | - | - | ||||
| ASH | wt% | <1.5 | <1.5 | <1.5 | |||||
| Graphene Content | wt% | 1-3 | 1-3 | 1-3 | 1-3 | ||||
| Carbon Content | wt% | 50-65 | 50-65 | 50-65 | XPS | ||||
| Oxygen Content | wt% | 30-50 | 30-50 | 30-50 | XPS | ||||
| pH=1-2, $110/g ; pH=3-4,$130/g (according to the content of solid calculationTNWGO-50 pH=3-4 $150/g ) | |||||||||
Storage instructions:
The product should be sealed and stored in a cool and dry place, it is recommended to use within six months after receiving the product.
